LC03-6R2
ELECTRICAL CHARACTERISTICS
Characteristic
Reverse Breakdown Voltage @ I t = 1.0 mA
Reverse Leakage Current @ V RWN = 5.0 V
Maximum Clamping Voltage @ I PP = 50 A, 8 x 20 m S
Maximum Clamping Voltage @ I PP = 100 A, 8 x 20 m S
Between I/O Pins and Ground @ V R = 0 V, 1.0 MHz
Between I/O Pins @ V R = 0 Volts, 1.0 MHz
Symbol
V BR
I R
V C
V C
Capacitance
Capacitance
Min
6.8
N/A
N/A
N/A
-
-
Typ
-
-
-
-
16
8.0
Max
-
20
15
20
25
12
Unit
V
m A
V
V
pF
pF
TYPICAL CHARACTERISTICS
10
8
6
4
2
0
16
14
12
10
8
6
4
2
0
-80 -60 -40 -20
0
20
40
60
80 100 120 140
-80 -60 -40 -20
0
20
40
60
80 100 120 140
T, TEMPERATURE ( ° C)
Figure 1. Reverse Voltage versus Temperature
T, TEMPERATURE ( ° C)
Figure 2. Reverse Leakage versus
Temperature
100
90
t r
PEAK VALUE I RSM @ 8 m s
20
18
80
70
60
50
40
30
20
10
t P
PULSE WIDTH (t P ) IS DEFINED
AS THAT POINT WHERE THE
PEAK CURRENT DECAY = 8 m s
HALF VALUE I RSM /2 @ 20 m s
16
14
12
10
8
6
4
2
8 x 20 m s Waveform
0
0
20
40
60
80
0
0
10
20
30
40
50
60
70
80
90 100 110
t, TIME ( m s)
Figure 3. 8 x 20 m s Pulse Waveform
I PP , PEAK PULSE CURRENT (A)
Figure 4. Clamping Voltage versus Peak Pulse
Current
http://onsemi.com
2
